C68 Fully Sealed Drainage-Free Automatic Bollard

Description

C68 Fully Sealed Drainage-Free Automatic Bollard

The C68 is a fully sealed automatic rising bollard designed for vehicle access control projects where conventional drainage pits create installation or maintenance challenges. Its 219 mm column, 600 mm rising height, modular structure and multiple configurations make it suitable for commercial entrances, campuses, parking facilities, industrial compounds and controlled-access sites.

Unlike an open or drain-dependent pit, the sealed structure is designed to reduce the entry of water, mud and sediment around the internal drive assembly. A tight annular gap, multiple sealing points and pressure-equalisation design support more stable operation in demanding outdoor environments. Site drainage, groundwater level and civil conditions must still be evaluated before installation.

Key Features

• Fully sealed, drainage-free structure: reduces dependence on a complex dedicated drainage pit.
• 219 mm column diameter and 600 mm rise: visible vehicle-control profile for project entrances.
• Modular removable assembly: designed to simplify inspection, replacement and maintenance.
• Dual upper-and-lower load-bearing structure: supports stable mechanical loading.
• Tight annular gap: helps reduce the entry of sand, mud and debris around the moving column.
• Pressure equalisation: helps manage internal pressure changes during operation.
• High-position installation: can simplify civil work compared with some conventional drainage layouts, depending on the site.
• Multiple project configurations: standard, reinforced, 36V battery and 36V high-strength versions.

Available Configurations

*Load figures are model specifications, not a substitute for site engineering or an impact-rating certificate. Final configuration, documentation and test requirements must be confirmed for each project before quotation.

Common Specifications

• Column diameter: 219 mm
• Rising height: 600 mm
• Standard/reinforced/battery cylinder wall: 6 mm
• High-strength cylinder wall: 10 mm
• Bearing plate thickness: 30 mm
• Battery version: 36V backup configuration; battery capacity options are available subject to project confirmation

Where It Is Used

The C68 can be specified for commercial building entrances, residential communities, campuses, factories, parking-control lanes and other restricted vehicle access points. It can form part of a wider entrance-control solution with licence plate recognition, access control, control cabinets and safety detection devices. Integration scope should be confirmed against the project drawings and required operating logic.

Installation Notes

“Drainage-free” describes the sealed bollard structure and reduced reliance on a dedicated internal drainage system. It does not mean that surface water, groundwater, soil bearing capacity or cable routing can be ignored. Before ordering, the installer should confirm excavation dimensions, foundation design, groundwater conditions, local drainage, conduit routing, controller position and maintenance access.

OEM/ODM and Project Support

Baisen Access supports overseas distributors, system integrators, contractors and project buyers with configuration selection, OEM/ODM discussion and system integration planning. Product appearance, controller logic, accessories, packaging and project documentation are confirmed according to order requirements.

Information Needed for a Quotation

1. Project country and application site
2. Required quantity and lane layout
3. Daily operating frequency
4. Power availability and whether battery backup is required
5. Required access-control or licence-plate-recognition integration
6. Groundwater, drainage and civil-work conditions
7. Required standards, test reports or tender documents

Frequently Asked Questions

Does a drainage-free bollard require no site drainage?

No. The sealed design reduces dependence on a conventional bollard drainage pit, but the complete site still needs suitable surface-water management and civil engineering.

Which C68 version should I choose?

The standard version suits general access-control projects. The reinforced version provides greater overlap depth. The 36V battery version is intended for sites requiring backup operation, while the high-strength version uses a thicker column and structure for demanding projects. Final selection should follow the project risk assessment.

Can the bollard connect to ANPR or access control?

Yes, project integration can be planned with licence plate recognition, access control and vehicle detection. Please provide the required operating sequence and interface requirements.

Is the price shown online?

No. This is a project-configured B2B product. Pricing depends on configuration, quantity, accessories, integration, packaging and destination.

Need a project recommendation? Read our drainage-free automatic bollard buyer guide, browse automatic bollards, or send your project requirements for a configuration proposal.
