BS-SY602R-406
描述
Product Name: 22T Hydraulic Single 升降柱 (Lifting Column)
Functional Features
● Warning Light: There is a warning light strip on the top of the column. The light strip lights up when the column is lifting or lowering, and the warning light for the ascending and descending status of the column is obvious;
● Lifting Speed: 150mm/s;
● Warning Sign: 5cm reflective tape, with night warning function;
● Installation Environment: Install according to the environment, and collagen can be used according to the on-site geological conditions;
● Passing Pressure: 50-ton container truck;
● Height after Rising: 600mm standard (±2mm);
● Control Mode: Control cabinet button control, three-button console remote control (standard), lighting control (optional);
● Operating Temperature: -20°C ~ 55°C (It is a normal phenomenon if the lifter is out of sync when the product is used below 0°C.);
● Lifting Method in Case of Power Failure: The backup power supply controls the solenoid valve to lower;
● Lifter: The lifting column can lift and lower continuously for 5000 times without failure, and the lifter lifts and lowers accurately;
● Water Immersion Performance: The lifting column is immersed in water for more than 72 hours, with no leakage, and can lift and lower normally;
● Control System: The dielectric strength, insulation resistance, and current discharge of the control system comply with the provisions of item 5.7 in GA/T 1343-2016.
● Warning Light: There is a warning light strip on the top of the column. The light strip lights up when the column is lifting or lowering, and the warning light for the ascending and descending status of the column is obvious;
● Lifting Speed: 150mm/s;
● Warning Sign: 5cm reflective tape, with night warning function;
● Installation Environment: Install according to the environment, and collagen can be used according to the on-site geological conditions;
● Passing Pressure: 50-ton container truck;
● Height after Rising: 600mm standard (±2mm);
● Control Mode: Control cabinet button control, three-button console remote control (standard), lighting control (optional);
● Operating Temperature: -20°C ~ 55°C (It is a normal phenomenon if the lifter is out of sync when the product is used below 0°C.);
● Lifting Method in Case of Power Failure: The backup power supply controls the solenoid valve to lower;
● Lifter: The lifting column can lift and lower continuously for 5000 times without failure, and the lifter lifts and lowers accurately;
● Water Immersion Performance: The lifting column is immersed in water for more than 72 hours, with no leakage, and can lift and lower normally;
● Control System: The dielectric strength, insulation resistance, and current discharge of the control system comply with the provisions of item 5.7 in GA/T 1343-2016.
Technical Parameters
● Input Voltage: AC220V ±10%
● Column Material: 304 stainless steel
● Column Diameter: Φ219mm (±0.5mm)
● Driving Mode: Independent integrated hydraulic system
● Protection Level: IP68
● Main Dimensions of Two Columns: It is recommended that the wall thickness of 1.2m column is 6mm (±0.5mm)
● Motor Power: 300W (input power 1200W)
● Lifting Force: 200Kg
● Lifting Speed: 150mm/s
● Warning Sign: 5CM reflective tape, with night warning function
● Control Cabinet Mode: 1 drag 6, 1 drag 3
● Input Voltage: AC220V ±10%
● Column Material: 304 stainless steel
● Column Diameter: Φ219mm (±0.5mm)
● Driving Mode: Independent integrated hydraulic system
● Protection Level: IP68
● Main Dimensions of Two Columns: It is recommended that the wall thickness of 1.2m column is 6mm (±0.5mm)
● Motor Power: 300W (input power 1200W)
● Lifting Force: 200Kg
● Lifting Speed: 150mm/s
● Warning Sign: 5CM reflective tape, with night warning function
● Control Cabinet Mode: 1 drag 6, 1 drag 3
